combiloop CL1G

THE MIRACLE FOR SMALL SPACES – FOR NEWCOMERS TO HIGH-PRESSURE

The attractively price entry-level product in the combiloop family fits perfectly into the unused space between bar loader and machine tool. Aesthetic in design and highly functional, with a high pressure of up to 70 bar and high-performance filters it is the optimum solution for temporary increases in pressure. combiloop CL1 G was designed for flexible, efficiency-boosting use on various tool machines.

Suitable for lathes by:
Citizen, DMG Mori, Manurhin, Star, Tornos, Tsugami, to name but a few.

Technical Data
Equipment
  • Approx. 500 x 400 x 680 mm (L x W x H)
  • < 70 bar, high-pressure pump as constant pump (robust gear pump)
  • Power supply 3∼/PE 400 V / 50 Hz
Flow rate
  • 9 / 16 l/min
Pressure
  • Progressive to 70 bar
Filter
  • Exchangeable filter, mesh, washable
Filter fineness
  • 40 μm, 60 μm
Operation
  • Cutting oil
  • Water emulsion (minimum 8% oil content)
Service connections
  • Up to 4 controllable service connections
Degree of machine contamination
more

FUNCTION

Baugruppenzeichnung der Hochdruckanlage combiloop CL1 G von Müller Hydraulik
Baugruppenzeichnung der Hochdruckanlage combiloop CL1 G von Müller Hydraulik

Caption:

  1. Modern housing
  2. High-pressure pump as gear pump
  3. Fine filter as single filter
  4. Control valve for smooth adjustment of the operating pressure
  5. Display: manometer
  6. Manifold with controllable service connections
  7. Status display + main switch
  8. Contamination indicator
